Fast and powerful
The horizontal Lewmar Pro-Series 700G Anchor
Windlass is ideal for boats up to 12m (38ft). It’s
DIY-ready, easy to install and housed in 100% 316 stainless steel,
making it well protected. With a push-button control and a built-in
manual emergency recovery system, anchoring has never been
easier.
Lewmar Pro-Series 700G Anchor Windlass
Features:
- Powerful motor providing fast line speed
- Manual emergency recovery equipped all you need is a common 1/2
socket wrench - Strong 100% 316 stainless steel, including control arm and
stripper - Maximum pulling power: 320kg (700 lb) for the 700 and 454kg
(1,000 lb) for the 1000 - Convenient above-deck installation
- For boats up to 12m (38ft)
- 5-year warranty
Lewmar Pro-Series 700G Anchor Windlass
Specifications:
- Dimensions: 245 x 178 x 146 mm
- Max Chain: 7mm (1/4in)
- Motor Supply: 12v
- Motor Power: 500w
- Maximum Pull: 320kg (700lb)
- Maximum Line Speed: 32 m/min (105 ft/min)
- Working Load Limit: 79kg (175lb)
- Normal Current Draw: 35 Amp
- Circuit Breaker: 50 Amp
- Weight: 8.5kg
- Chain: 6mm DIN 766 / 7mm DIN 766 / 1/4″ ISO G4 / 1/4″
BBB - Rope: 12mm 3-strand and 8-plait
What’s in the box:
- Windlass
- Base gasket seal
- Fast mounting studs
- Installation wrench
- Circuit breaker
- Dual-direction solenoid
- Guarded rocker switch
Note: A Pro-Fish conversion kit is available
for the Pro-Series Windlass to allow freefall. Wireless remote can
only be used if a contactor/solenoid unit is fitted
